GREETINGS FROM PRESIDENT

OUR COMPANY STARTED OUR BISUNESS AS A DIE PRESSING FACTORY IN 1967. WE TRANSFERRED OUR TECHNOLOGY TO EXTERNAL CUTTING OF PCB AND STARTED MANUFACTURING PCBs FROM 1982.

WITH OUR COMPANY POLICY “MAKE ALL THE RELATED PEOPLE AND PARTIES HAPPY”, WE DO OUR BUSSINESS CONSIDERING EXCITEMENT AND SATISFACTION OF OUR CUSTOMERS, EMPLOYEES, THEIR FAMILIES AND LOCAL PEOPLE IN THIS AREA.

THE ENVIRONMENTAL CHANGE IS SO RAPID WORLD-WIDE. BUT WE WILL CONTINUE TO SUPPLY EXCITEMENT AND SATISFACTION STANDING ON THE WORLD LEADING MANUFACTURING TECHNOLOGY AND INNOVATION.

THE TECHNICAL INNOVATIONS IN COMPUTER CHIPS ARE SO RAPID NOW. BUT OUR INDUTRY IS ALSO FACING HEAT PROBLEM. WE SUCCEEDED TO MANUFACTURE AUTHENTIC PCBs THAT HAS SAME HEAT RADIATION CAPABILITY AS CERAMIC PCBs.

OUR MANUFACTURING AND INNOVATION CAN BE ACHIVED WITH CHALLENGES OF OUR EMPLOYEES. WE CONTINUE TO CHALLENGE WITH OUR POLICY “KEEP PROMISES, KEEP STEPPING FORWARD FOR BIG GOALS”.

DAIWA CORPORATION
President Eiji Yoshimura

COMPANY PROFILE

COMPANY NAMEDAIWA CO., LTD.
PRESIDENTEIJI YOSHIMURA
ADDRESS394-0004, 4-1-25, SHINMEI-CHO, OKAYA-SHI, NAGANO PREF. JAPAN
TEL+81-266-22-5758
FAX+81-266-23-7324
CAPITAL MOUNTJPY 95,000,000
NUMBER OF EMPLOYEES73
ANNUAL SALESJPY 1,190,000000
OUR BUSIESSDEVELOPMENT, PRODUCTION AND SALES OF PRINTED CIRCUIT BOARDS
ISO ACQUISITION9001(2015 VER.) AND 14001 (2015 VER.)

COMPANY HISTORY

DEC. 1967COMPANY FOUNDATION AND STARTED DIE PRESS BUSINESS
AUG. 1982STARTED PCB MANUFACTURING
DEC. 1988INSTALLED MULTI-LAYER PRESS MACHINE AND STARTED SELF MANUACTURING OF MULTI LAYERED PCBs
DEC. 1992STARTED MANUFCACTURING BUILD-UP PCBs
OCT. 1996MAS-PRODUCTION OF BUILD-UP PCBs
JUN. 1998NEW METHOD OF BUILD-UP PCBs CALLED "AGSP" WAS STAETED
NOV. 2000ACQUIRED ISO 9002
ARP. 2001ACQUIRED INTERNATIONAL PATENT OF NEW BUILD-UP "AGSP"
JUN. 2003ACQUIRED ISO 9001(2000 VER.)
JUN. 2007ESTABLISHED DENKA AGSP COMPANY
IN JOINT WITH DENKI KAGAKU KOGYO CO. LTD.
NOV. 2008ACQUIRED ISO 14001(2004 VER.)
MAY 2011SUCESSFULLY DEVELOPPED HIGH RADIATION PSB "DPGA"
Daiwa Process Global Advance
APR. 2012CHANGED NAME OF "DENKA AGSP" TO DAIWA CORPORATION
MAY 2015EXPANEDED NC DRILLING FACILITIES
MAY 2016SUCCESSFULLY DEVELOPPED "DPGA-M" AND "DPGA-S", THE HIGH RADIATION WITH CONTINUITY CUIRCUTS
JUL. 2016INSTALLED THE DIRECT IMAGING MACHINE FOR CUIRCUIT CREATION
FEB. 2017APPLICATION OF INTERNATIONAL PATENT FOR "DPGA" IS SUBMITTED
MAY 2017SUCCESSFULLY DEVELOPPED "DPGA-EF", THE COPPER INLAY PCB
SEPT. 2017ACQUIRED ISO 9001 (2015 VER.)
NOV. 2017ACQUIRED ISO 14001(2015 VER.)
DEC. 2017STARTED MAS-PRODUCTION OF HIGH RADIATION PCB "DPGA"
MAR. 2018ABSORBED DAIWA CORPORATION
MAY 2018INSTALLED AUTO EXPOSURE MACHINE OF SOLDER RESIST AND INK-JET SILK PRINTING MACHINE
JUN. 2018INSTALLED AUTO CUT SAW AND FULL AUTOMTIC PROBE CHECKER
JUN. 2019INSTALLED FULL AUTOMATIC NC DRILLING MACHINE
JUL. 2021INSTALLED FULL AUTOMATIC PROBE CHECKER (2ND UNIT)
MAR. 2023SUCCESSFULLY DEVELOPPED "DPGA-AIN", THE PCB WITH INSULATTED RADIATION PINS







EXPAND THE MAP

BUSINESS HOURS = 8:30-17:30(EXCL.SAT./SUN. OR HOLDAYS) TEL +81-266-22-5758 BUSINESS LOCATIONS : HEADQUATER IN NAGANO PREF., TOKYO AND OSAKA
